Build Package Suited For 2018+ Subaru Crosstrek

Build up your Subaru Crosstrek with this convenient package to get your adventure started.

We put together a complete suspension system and a rally light bar with led lighting kits suited for your Crosstrek for 4WD touring while still maintaining its daily drivability.

Just add fuel.

All Terrain Systems (ATS) Suspension Lift Kit

Your adventuremobile turned up a notch.

The All Terrain Systems (ATS) Suspension Lift Kit suited for the Subaru Crosstrek is a complete suspension system for greater handling and control without compromising safety and comfort. Our suspension system includes performance coils for greater stability and improved driving dynamics or if choosing to go with our Spec-C system will include heavier performance coils for additional carrying capacity. Engineered with extended travel twin-tube gas struts, derived from our military-grade suspension, ATS provides enhanced durability and reliability in both on- and off-road environments. And with a two-inch lift, larger tires can be fitted for enhanced stability in inclement weather or on challenging roads. Ground clearance increases to an impressive 10.7 inches, so you can adventure further wherever the road takes you.

The capability to go further with the confidence you need to get back.

"Safety, comfort and performance—it’s a well-rounded package that is really quite impressive."

Nate Tennis
Rally Driver and Lead Instructor
DirtFish Rally School

Rally Light Bar

The included rally light bar is a stable solution to mount one of our included lighting options.  This could be side shooters, spot or combo lights, megatom LEDs, light bars and more.  Built specifically for the Subaru Crosstrek, the rally light bar enhances the style of the OEM bumper.  This is fully power-coated to protect from rust and is a simple bolt-on installation made from steel tubing.

Specifications

• Estimated Lift Height: 2"
• ATS Medium Load Support:
• 0-110LBS Front
• 0-440LBS Rear


• ATS Spec-C Heavy Load Support:
• 110-176LBS Front
• 440LBS-GVM Rear

This Kit Includes:

• 2" ATS Suspension Lift Kit:
• Front and Rear Ironman 4x4 ATS coilovers (pre-built struts and springs for front and rear)
• Subframe spacer kit
• Sway bar spacer kit
• Extended exhaust hanger bracket
• All mounting hardware for installation


• Rally Light Bar
• LED Lighting Kit for Rally Light Bar (depending on selection will include one of the following):
• (2) 5" Side Shooter LED Lights
• (2) 5x7" LED Driving Lights
• (2) 7" Blast Phase II Spot LED Lights
• (2) 7" Blast Phase II Combo LED Lights
• (2) 7" Meteor LED Lights
• (2) Cosmo Dual LED Lights
• 19.5" LED Light Bar


• Each lighting kit comes with a wiring harness

Installation

 View Instruction Sheet 2018-2020

 View Instruction Sheet 2021+

Suspension:

• Bolt-on system (no cutting or welding necessary)
• May not be compatible with trailer hitches so double check your clearances ahead of install

 View Instruction Sheet

Suspension Installation Video:
